Cultivating roller FACA

front-mounted

Overview
The FACA roller is designed to lay down and injure cover crops without disturbing the soil surface to limit re-sprouting. It increases aggressiveness when ballasted (water or additional weights). The roller is fitted with 10 twisted blades 100 × 10 mm on a 607 mm diameter roller.

Main functions

• Lay down and damage cover crops while preserving the soil surface to reduce germination triggers
• Ballastable with water or additional weights to increase pressure and effectiveness
• Blade arrangement designed to damage vegetation without tilling

Features

• Self-directing hitch with automatic realignment (on applicable models)
• Transport locking latch
• Front-mounted ball joint
• Automatic hitch options

Technical data (table)
Type; RF 300 F; RF 350 F; RF 350 AD; RF W400 AD; RF W450 AD; RF W480 AD; RF W500 AD; RF W600 AD
Hitch; Fixed; Fixed; Auto; Auto; Auto; Auto; Auto; Auto
Roll width; –; –; –; 2,30 m; 2,30 m; 2,30 m; 2,30 m; 2,30 m
Working width; 2,75 m; 3,25 m; 3,25 m; 4,00 m; 4,50 m; 4,80 m; 5,00 m; 6,00 m
Overall width; 3,00 m; 3,50 m; 3,50 m; 4,25 m; 4,75 m; 5,05 m; 5,25 m; 6,25 m
Weight; 830 kg; 940 kg; 1,130 kg; 1,560 kg; 1,670 kg; 1,750 kg; 1,790 kg; 1,980 kg

Use & field testing
Field trials were carried out on a cover-crop platform at La Conillais farm to evaluate species sensitivity to the FACA roller. Results show varying resistance among species and provide visual before/after comparisons useful for planning mechanical destruction prior to main crop sowing.

Technical specifications

• Blades: 10 twisted blades, 100 × 10 mm
• Roller diameter: 607 mm
• Ballasting: possible with water or additional weights to increase aggressiveness
• Available models: RF 300 F, RF 350 F, RF 350 AD, RF W400 AD, RF W450 AD, RF W480 AD, RF W500 AD, RF W600 AD
• Hitch options: Fixed or Automatic (self-directing hitch with automatic realignment)
• Transport locking latch included; front-mounted ball joint and automatic hitch options available
• Working widths: 2.75 m to 6.00 m depending on model
• Overall widths and weights vary by model (see technical data)
• Brand: SKY Agriculture
