Horse restraint system 2080010

Presentation
Monobloc gynecological restraint bar designed to immobilize a mare for gynecological examinations, ultrasound and reproductive procedures. The unit is mounted on a movable platform for on-site relocation. Construction and padding are specified for use in equine reproduction environments.

Dimensions

• Height: 1800 mm
• Width: 800 mm
• Platform dimensions: 1200 mm x 2800 mm

Features

• 1 pivoting side panel with 500 mm high fill and foam/PVC protective panel
• 1 fixed side panel with full plywood facing, 18 mm film-coated, and foam/PVC protective panel
• 1 rear gate and 1 front gate upholstered with textured rubber matting
• 1 pivoting ultrasound shelf
• Reinforcements with steel brackets
• Unit mounted on a platform covered with a 10 mm textured rubber mat and 300 x 300 mm base plates
• Frame in hot-dip galvanized steel

Technical specifications

• Total height: 1800 mm
• Total width: 800 mm
• Platform: 1200 mm x 2800 mm
• Pivoting side panel: height 500 mm (foam/PVC panel)
• Fixed side panel: 18 mm film-coated plywood (foam/PVC panel)
• Gate upholstery: textured rubber matting
• Ultrasound shelf: pivoting
• Fixing base plates: 300 x 300 mm
• Platform mat: 10 mm thick (textured)
• Structure: hot-dip galvanized steel frame
• SKU (internal reference): 2080010
• Associated categories: Gynecological bars, Reproduction equipment
