Pot packing machine LINR

automaticwith conveyor

Overview
The LINR is a high-speed linear pick-and-place robot driven by servo drives, designed for fast automated handling of plant pots on production lines. It is available in widths from 2,000 mm to 6,000 mm and supports plug diameters from 6 to 35 mm.

Options

• Advancing system for mobile containers or trolleys
• Shift movement in the pot fork
• Wide belt for placing pots into (shuttle) trays
• Fully automatic change-over system for pot forks
• Individually driven moving pot forks for increased picking & placing flexibility

Specifications

• Operators: -
• Plug diameter: 6 - 35 mm
• Capacity per hour: 1,000 - 10,000 pots

Technical specifications

• Type: High-speed linear moving pick-and-place robot
• Drive: Servo drives
• Available widths: 2,000 mm to 6,000 mm
• Plug diameter range: 6 - 35 mm
• Capacity: 1,000 - 10,000 pots per hour
• Options: advancing system for mobile containers/trolleys; shift movement in pot fork; wide belt for (shuttle) trays; fully automatic change-over for pot forks; individually driven moving pot forks
