Slurry conveyor TP10

beltrollerinclined

Overview
The VALLI TP 10 manure conveyor is designed for rapid removal and transport of manure in livestock facilities and agricultural settings. It combines a 600 mm rubber belt with a smooth-running roller support and a motorized waterproof drum to ensure consistent operation in low temperatures down to -40°C.

Features

• Fast cleaning and manure removal operations
• Belt width: 600 mm (2 ft)
• Operating speed: 75 m/min (246 ft/min)
• Drive: motorized by waterproof drum
• Motor drum diameter: 220 mm (8.5 inches)
• Running rollers system (sliding/rolling support for the belt)
• Rubber belt suitable for temperatures down to -40°C

Model specifics

• Designation on page: TP10 model
• Main components: rubber belt, running rollers, motorized drum

Technical specifications

• Belt width: 600 mm (2 ft)
• Speed: 75 m/min (246 ft/min)
• Drive: motorized by waterproof drum
• Motor drum diameter: 220 mm (8.5 inches)
• Support: reliable smooth-running roller system
• Belt material: rubber, suitable for conditions down to -40°C
