Tractor stone crusher NT series

Summary
The DT Series by AGARIN provides increased power and precision for heavy-duty field conditions. The reinforced frame and double transmission deliver steady, uniform operation even on hard ground. The machine is configured for superfine crushing and stable performance under load.

Main data

• Mechanical power: 250 HP
• Working width: 1750 mm
• Weight: 1670 kg

Standard equipment

• High-strength steel chassis
• Three-point hitch, category 2-3
• Reversible hammers in Hardox steel
• Hydraulic rear door
• PTO drive shaft
• Lateral double transmission with belts
• Bondioli group: 175-DTR → 2125 1"3/4; 205-DT2R → 2155 1"3/4; 230-DT2R → 2155 1"3/4
• Double row of protective chains
• Rear depth control wheel
• Double rear depth control wheel
• Protections according to regulations
• CE certified

Optional equipment

• Tungsten-tipped hammers
• Pulley set for superfine crushing
• Technology developed by AGARIN

Key elements / Notable technical features

• Rotor with floating hammers to absorb impact and protect bearings
• Double cardan transmission ensuring balanced, constant power across the rotor
• Capacity to crush stones up to 35 cm in diameter
• Double depth-control wheels for precise adjustment and uniform work on uneven terrain
• Configurable for superfine crushing to adapt output grain size to soil hardness

Technical specifications

• Model: 175-DTR
• Machine width (mm): 1800
• Working width (mm): 1750
• Machine height (mm): 1170
• Machine length (mm): 2360
• Minimum power at 0.5 km/h (HP): 100
• Minimum power at 2 km/h (HP): 150
• Mechanical power (HP): 250
• Rotor diameter (mm): 570
• PTO (rpm): 1000
• Number of hammers: 20
• Working depth (cm): 30
• Hydraulic circuit: 1 double-acting
• Weight (kg): 1670
