Mounted wood chipper TC-160

PTO-driven

Overview
The AGARIN TC-160 is a compact flail mulcher engineered for orchards and citrus plantations where narrow passage and maneuverability are essential. Its reduced overall width and weight allow work beneath tree canopies and on moderate slopes while delivering a fine, uniform shred with economical power use.

Standard equipment

• High-strength steel chassis
• Reversible three-point hitch, category 2
• Anti-clogging rotor
• Hardox steel swing hammers
• Cardan shaft transmission
• Bondioli 2071 1" 3/4 RL gearbox
• Safeguards compliant with standards
• CE certification

Optional equipment

• Fixed hammer kit
• Reversible swing hammer kit
• Anti-stress electronic kit
• PTO gearbox for 1000 rpm
• Hydraulic starter
• Solid tyres
• Industry 4.0 connectivity kit
• Double freewheel group

Key features

• Narrow, compact design ideal for citrus, orchard rows and tight planting layouts
• Mobile-hammer rotor adapts to incoming material and prevents blockages for consistent shredding
• Accepts branches up to 18 cm diameter
• AGARIN shredding system with optimized hammer and counterhammer for finer, more efficient mulch
• Upper feeder visible from tractor cab for easier operation

Specifications
MODEL: TC-160

Machine width (mm): 1950
Machine height (mm): 1000
Machine depth (mm): 1350
Minimum recommended power (HP): 65
Maximum admissible power (HP): 125
Cutting diameter (mm): 420
PTO: 540
Number of hammers: 66
Rows of replaceable and fixed counterknives: 2+1
Number of XPB belts: 4
Hydraulic circuit: 1 double-acting

Technical characteristics

• Declared weight: 950 kg
• Working width indicated: 1600 mm
• Displayed mechanical power: 65 HP (minimum recommended)
• Cutting capacity: branches up to 18 cm
• Shredding system with optimized hammers and counterknives (Hardox hammers as standard)
• Cardan transmission and Bondioli 2071 1" 3/4 RL gearbox
• Protections and CE certification included
