Automatic tray filler

Overview
We offer an automatic pacing unit for the 2-Row FiberCell Filling Machine to increase automation and throughput. Built with a robust construction, the line is designed for high performance, reliability and an ergonomic operator interface suited to nursery environments. The machine places plugs with diameters from Ø45 to Ø60 mm and adjustable lengths up to 100 mm. It performs best with fine, particle-free substrate and is especially suitable for propagation of tree species such as eucalyptus and acacia. The substrate hopper includes a level sensor and optional automated supply solutions.

Key features

• Automatic pacing unit available to enhance automation and throughput
• Durable construction for long uptime in forestry nursery operations
• Handles FiberCell diameters Ø45–60 mm and lengths up to 100 mm (adjustable)
• Optimal with fine substrate free of large particles for uniform filling
• Substrate hopper with level sensor; options for automated substrate supply
• Trays can be fed from left or right, manually or via optional buffer conveyor with integrated destacker
• Placing unit programmable to position paper plugs in different patterns
• Integrated adjustable spike dibbler for various tray configurations
• User-friendly color touchscreen for monitoring and adjustments; optional remote support if on-site internet available
• Easy to clean; typically operated by one operator
• Production capacity up to 4,000 cells per hour depending on cell size and substrate

Product Leaflets

• 2-Row Fully Automatic FiberCell Filler - English (leaflet available)

Technical specifications

• Dimensions (LxWxH) mm: 6750x1850x2500
• Weight (kg): Approx. 2000
• Electrical Power: 3x400 V, 50/60 Hz, 16 A + 10 A
• Compressed Air: 700l at 6 bar
• Capacity: Up to 4000 cells/hour (Depending on cell length, cell diameter & substrate)
• FiberCell diameter (mm): Ø45-60mm
• FiberCell length (mm): Up to 100mm
