Mechanical weeder SIGMA

tractor-mounted

Description
The SIGMA tined weeder by Feelcrop delivers precise mechanical weeding for a wide range of crops and crop stages. Its adjustable working pressure and independent tines maintain effectiveness from early to late interventions. Multiple adjustment options enable adaptation to different soil conditions and crop heights.

Characteristics

• Adjustable working pressure for early to late-stage interventions
• High clearance under the frame for late passes
• Versatile tines compatible with many crop types
• Pressure range: 500 g to 5 kg
• Continuous hydraulic adjustment with indicator
• 6 rows of tines with 25 mm spacing
• Ø 7 mm independent tines
• 3-point oblong holes for terrain following on slopes
• Pivoting rear wheels with pin adjustment
• Large-diameter wheels with agricultural tread
• Unhitching stand for folded storage and transport
• Road signs supplied as standard

Our strengths

• Independent-pressure tines for consistent soil contact
• Pivoting rear wheels for precise depth control
• Unhitching stands for compact folded storage
• Continuous hydraulic pressure adjustment for on-the-go tuning

Videos (available on the product page)

• SIGMA (main video)
• arriereSIGMA (rear view)
• avantSIGMA (front view)

Documentation (available)

• SIGMA commercial brochure (PDF)

Technical specifications

• Working pressure adjustable: 500 g – 5 kg
• Continuous hydraulic pressure adjustment with indicator
• 6 rows of tines
• Tine spacing: 25 mm
• Tine diameter: Ø 7 mm (independent tines)
• High clearance under frame for late-stage operations
• 3-point oblong holes for terrain following (suitable for hilly ground)
• Pivoting rear wheels with pin adjustment
• Large diameter wheels with agricultural tread
• Unhitching stands for folded storage
• Road signs supplied as standard
