GNSS leveling system MIG-PRO series

Modular GNSS land leveller MIG-PRO - Fontana
A compact trailed machine with working widths from 1.50 to 2.50 m for agriculture, sports surfaces, greenhouses and confined spaces; configurable for Laser or GNSS control.

MIG-PRO is a modular trailed land leveler available with a 1.50, 2.00 or 2.50 m blade. Its 1.50 m closed configuration facilitates work in confined areas. The four-wheel oscillating-bogie carriage and hydraulic tilt correction support consistent blade behaviour, while Laser or GPS readiness allows compatible control systems to be integrated.

Range and technical data
- MIG-PRO 150; Blade width: 1.50 m; Tractor power: 15/50 HP; Weight: 560 kg; Delivery configuration: 150 cm; Configurations with supplied equipment: 150 cm; Optional extensions: 200 and 250 cm.
- MIG-PRO 200; Blade width: 2.00 m; Tractor power: 25/60 HP; Closing type: Manual; Weight: 595 kg; Delivery configuration: 200 cm; Configurations with supplied equipment: 150 and 200 cm; Optional extensions: 250 cm.
- MIG-PRO 250; Blade width: 2.50 m; Tractor power: 35/70 HP; Closing type: Manual; Weight: 630 kg; Delivery configuration: 250 cm; Configurations with supplied equipment: 150, 200 and 250 cm; Optional extensions: —

Main applications
- Field preparation and grading.
- Construction and maintenance of sports-field surfaces.
- Grading in gardens, greenhouses and areas with restricted access or working space.

Main customer benefits
- Easier access in confined spaces thanks to the 1.50 m working configuration available across the series.
- More consistent blade behaviour through the four-wheel oscillating-bogie carriage and hydraulic tilt correction.
- Choice of 1.50, 2.00 or 2.50 m nominal blade widths to match different operating requirements.
- Simpler integration of compatible systems through Laser or GPS control readiness.
- More progressive hydraulic movement available with the optional proportional solenoid valve.
- Articulated tractor connection through the Fontana-exclusive three-joint drawbar.

Why Choose Fontana
- Premium materials: selected without compromise to support structural strength, reliability, consistent performance and long machine life.
- Compact transport from the factory: 2.70 m long, 1.50/2.00 m wide and 1.23 m high, with a weight from 560 to 630 kg, simplifying loading, shipment and handling.
- Compact transport between fields: rapid transfers within the tractor’s transport envelope, without trailers or exceptional transport.
- Multiple working widths with one machine: a configuration that adapts to different operating requirements.
- Integrated engineering: mechanics and hydraulics work in harmony, while Laser/GPS readiness allows compatible electronic control systems to be integrated.
- Higher field productivity: broad working coverage combined with a compact transport footprint.
- Lower operating costs: less downtime, simpler logistics and better use of the tractor.
- Long-term value: responsive support, technical assistance and original spare parts over the long term; Fontana still supports machines purchased up to 40 years ago.

Full description
The MIG-PRO series is designed for surface preparation and grading where compact dimensions, control and adaptability matter: fields, sports areas, gardens, greenhouses and other confined spaces. The range includes the MIG-PRO 150, 200 and 250, with nominal blade widths of 1.50, 2.00 and 2.50 m respectively.
The four-wheel carriage with oscillating bogies, combined with hydraulic tilt correction, supports consistent blade behaviour during operation. The three-joint drawbar, a Fontana-exclusive solution, provides an articulated connection to the tractor. The standard tractor-powered hydraulic system uses a damped ON-OFF solenoid valve.
Compact transport, maximum productivity. For shipment from the factory, the series has compact overall dimensions: 2.70 m long, 1.50/2.00 m wide and 1.23 m high, with a weight from 560 to 630 kg. This simplifies loading, handling and logistics. MIG-PRO also moves quickly between fields within the tractor’s transport envelope, reducing downtime and operating costs. In the field, the 150, 200 and 250 models provide multiple working configurations with one machine.
