Towed fertilizer spreader XT series

granular

Overview
Trailed fertilizer spreader XT (models XT160H / XT240H) engineered for high work rates and precise bulk-product distribution. 3° inclined belt and hopper geometry ensure efficient emptying and optimal load transfer to the tractor for improved traction and ride stability.

3° inclined belt and hopper

• The 3° incline enables complete emptying at the rear, preventing material settling in front of the hatch.
• Higher weight at the front of the loaded hopper transfers load to the tractor axle for maximum grip.
• The machine remains stable even when unladen, ensuring consistent ride comfort.

Flow accuracy
Mechanical belt drive by crown and pinion delivers a flow rate strictly proportional to forward speed and is insensitive to wheel slip across varied terrain. 800 mm wide feed conveyor with permanent self‑centering (cylindrical‑conical drive rollers) and hopper slopes optimised for free‑flowing bulk materials.

Hydraulic boom — dosing and section control

• Double row of stainless steel valves guarantees accurate dosing right to the boom end (up to 4 t/ha).
• Valves can be optionally adjusted automatically according to forward speed to maintain consistent distribution under varying conditions.
• Boom manages up to 5 sections and 3 spreading widths for high precision down to the last pass.

Warranty
A 7‑year anti‑perforation corrosion warranty is provided for DX, X and XT fertilizer distributors manufactured from 1 September 2019.

Simplify your settings

• Customise your machines
• Save and recall your settings
• Record your work

Technical specifications

• Type: XT160H / XT240H
• Hopper capacity: XT160H = 13,000 l; XT240H = 15,500 l
• Overall width: 2.55 to 3.00 m (both models)
• Loading height: XT160H = 2.78 to 2.94 m*; XT240H = 3.06 to 3.14 m*
• Power requirements: XT160H = 130–150 hp; XT240H = 180–220 hp
• Weight (indicative) weighed version: XT160H = 4,900 kg; XT240H = 6,900 kg
• Axle: XT160H = 140 mm; XT240H = 2 x 140 Tandem (rear follower)
• Tires: XT160H = 2 x 600/60 R30.5; XT240H = 4 x 650/55 R26.5
• GVW: XT160H = 15,900 kg; XT240H = 23,900 kg
• Hopper dimensions (both): 5.35 x 2.06 m
• Total length (both): 8.39 m
