Sunflower harvesting header PLEG series

foldingaugerfor combine harvesters

Description
Increase productivity with the TORT folding header. Easy handling with fold/unfold in under 1 minute. Designed for combine harvesters with cab-controlled folding using the machine's original controls.

Main features

• Center-fold design to reduce couplings and moving components.
• Dual left-right driveline with independent cutterbars and two gearbox assemblies.
• Folding/unfolding from the cab using original machine controls.
• Large-diameter auger (630 mm) with retractable fingers along the entire cutter width.
• Automatic driveline coupling without leaving the combine.
• Complete SCH cutting system.
• Stainless steel feed floor to improve crop flow.

Optional

• Side rapeseed knives
• Lighting and reflectors kit
• Hydraulic reel kit (for machines without reel)
• Double skid sensor per side
• Reel height and speed control
• Special sunflower trays for folding headers
• Adjustable dividers

MODELS (table)
Model | Feet | Working width | Total width unfolded | Folded width | Weight
PLEG40 | 13.5 | 4.00 m | 4.48 m | 2.50 m | 1900 kg
PLEG45 | 15 | 4.50 m | 4.94 m | 2.72 m | 1925 kg
PLEG48 | 16 | 4.80 m | 5.24 m | 2.87 m | 1950 kg
PLEG51 | 17 | 5.10 m | 5.54 m | 3.02 m | 2183 kg
PLEG54 | 18 | 5.40 m | 5.85 m | 3.18 m | 2200 kg
PLEG57 | 19 | 5.70 m | 6.15 m | 3.33 m | 2262 kg
PLEG60 | 20 | 6.00 m | 6.45 m | 3.46 m | 2350 kg
PLEG63 | 21 | 6.30 m | 6.75 m | 3.63 m | 2388 kg
PLEG66 | 22 | 6.60 m | 7.05 m | 3.79 m | 2480 kg
PLEG69 | 23 | 6.90 m | 7.40 m | 3.94 m | 2542 kg
PLEG72 | 24 | 7.20 m | 7.70 m | 4.09 m | 2620 kg
PLEG75 | 25 | 7.50 m | 8.00 m | 4.24 m | 2730 kg

Technical specifications / features

• Center folding to reduce moving components and couplings.
• Dual driveline with independent cutterbars and two gearbox units.
• Cab-controlled folding/unfolding using original machine controls.
• 630 mm auger with retractable fingers along the cutting width.
• Automatic driveline coupling (no need to leave the combine).
• Complete SCH cutting system.
• Stainless steel feed floor for improved crop flow.
• Available options: side rapeseed knives, lighting/reflector kit, hydraulic reel kit, double skid sensor, reel height and speed control, special sunflower trays, adjustable dividers.
• Available models: PLEG40, PLEG45, PLEG48, PLEG51, PLEG54, PLEG57, PLEG60, PLEG63, PLEG66, PLEG69, PLEG72, PLEG75 (see table for dimensions and weights).
