Nursery plants transplanter FlexSorter-S

automatic

Short description
The FlexSorter-S is a plug transplanter and multi-class selection machine designed for plug-grown seedlings. It combines transplanting, gapping and packing into a single processing step to reduce handling and avoid double handling damage.

Overview
The FlexSorter-S extracts seedlings from donor trays using in-house developed plant grippers and a pusher-pin system from below. Plants are handled only once: lifted for inspection, classified and transferred to destination trays or belts according to grade.

How it works

• Plant grippers lift seedlings to create space for visual or camera-based quality assessment.
• Approved seedlings are transferred grade by grade to selected destination belts.
• Classification count depends on the number of destination belts, up to four grades.
• Discarded seedlings and empty plugs are routed to a waste belt for removal.
• Selected trays are combined per class for downstream packing or processing.
• The machine and imaging system include an operator interface with integrated self-diagnosis for simplified maintenance.

Benefits

• Integrates transplanting and multi-class selection in one pass, reducing double handling and plant damage.
• Enables efficient single-pass grading and high throughput.
• Designed for easy operator interaction and rapid fault diagnosis.

Technical specifications

• Operators: 1
• Plug diameter: 9 - 60 mm
• Capacity per hour: 5,000 - 20,000 plugs
• Maximum number of grades/classifications: 4
• Plant grippers with pusher pin extraction system
• Waste belt for discarded seedlings and empty plugs
• Combination of selected trays per class
• Imaging system and user interface with integrated self-diagnosis
