Grain separator

aircentrifugal

Product overview
Cyclone separators are efficient mechanical devices for separating dust from gas streams. They deliver effective particle separation with high air-to-solids ratios while occupying minimal footprint. Cyclone separators are suitable for removing bulk dust from aspirated air; when residual dust requirements are moderate or fine dust content is low, the cleaned air can be discharged to atmosphere.

Key benefits

• Efficient separation with typical optimal pressure drops from 5 mbar to 15 mbar depending on model and flow rate.
• Hygienic options — available in mild steel and stainless steel constructions for hygiene-sensitive industries such as food processing and milling.
• Compact footprint — multiple sizes and compact designs to match different plant layouts while maintaining high air-to-solids ratios.

Key features / Models

• Compact cyclone separator — general compact design for applications with moderate dust separation needs.
• Cyclone separator LCGA — model family designed to guarantee purified air for general applications.
• Cyclone separator MGXE — compact unit with volumetric flow range 2.5 to 60 m³/min; optimal pressure drop 5 to 10 mbar; balances separating efficiency with minimal space requirements.
• Cyclone separator MGXG — large-capacity unit with volumetric flow range 35 to 600 m³/min; optimal pressure drop 7 to 15 mbar; suited for higher flow rates and bulk dust removal.
• Cyclone separator MGXH — compact unit with volumetric flow range 2.5 to 60 m³/min; optimal pressure drop 5 to 10 mbar; designed for high operational reliability.

Applications
Cyclone separators are used across industries to remove dust from aspirated air, including food processing, milling and other processes requiring dedusting. For applications with moderate residual dust requirements or limited fine dust, the cleaned air may be exhausted to atmosphere.

Technical specifications

• Volumetric flow ranges by model: MGXE / MGXH: 2.5 to 60 m³/min; MGXG: 35 to 600 m³/min.
• Optimal pressure drop ranges: MGXE / MGXH: 5 to 10 mbar; MGXG: 7 to 15 mbar; general machines: 5 to 15 mbar.
• Construction materials: mild steel or stainless steel versions available for hygiene-sensitive applications.
• High air-to-solids ratio capability for efficient bulk dust separation.
• Compact designs available to minimise space requirements; a wide range of sizes to suit various process footprints.
• Typical use: dedusting of gas flows; cleaned air may be exhausted depending on residual dust limits.
