Square baler MSB400

smallwith bale wrappersilage

Overview
Compact, cost-efficient silage baling solution for smallholder livestock operations (goats, sheep, backyard cattle). Produces 30–35 kg bales to enable year-round feed storage, converts surplus green fodder into preserved silage with up to 18 months shelf life, and is designed for portability and straightforward farm use.

Key Features

• Compact Bale Output: Produces 30–35 kg bales—easy to handle, stack, and transport for small-scale operations.
• Preinstalled Delivery: Comes fully assembled and ready to use, reducing on-site installation time.
• Efficient Wrapping System: 3–4 layers internal wrapping and 5–6 layers external wrapping for extended preservation.
• Hydraulic Operation: Hydraulic system for consistent bale formation and reduced operator effort.
• Chain-Driven Elevator: Integrated conveyor for efficient forage feed-in and minimal manual handling.
• Electric Power Input: Designed for a 3-phase electrical supply suitable for rural microgrids.

Design & Mobility

• Compact Bale Dimensions: 400 mm × 400 mm bales suited to limited farm storage and manual handling.
• Robust Wheel System: Two rubber wheels with cast-iron hubs to support machine weight and field movement.
• Towing Friendly: Equipped with towing hooks for transport between fields and storage locations.
• Rural-Ready Engineering: Narrow footprint and simple construction for access on small plots and farm tracks.

Service & Support

• On-site installation assistance, practical operator training, and maintenance guidance available.
• Spare parts supply and after-sales service network to support rural operations.

Technical specifications

• Output: 30–35 kg bales
• Compaction rate: 650–675 kg/m3
• Operating system: Hydraulic pump and motors
• Recommended power source: 5 Hp electric motor, 3 phase, 415 V
• Machine weight (dry): 820 kg
• Bale dimensions: 400 mm × 400 mm
• Wrapping: 3–4 internal layers; 5–6 external layers
