Vertical feed mixer MAK-30-12towedfront dischargerear discharge
Add to favorites
Compare this product
Characteristics
- Auger orientation
- vertical
- Mobility
- towed
- Discharge type
- front discharge, rear discharge
- Number of screws
- 2-auger
- Other characteristic
- with weighing system, PTO-driven
- Capacity in m³
30 m³
(1,059.4 ft³)
Description
Technical Features:
Length: 7800 mm
Width: 2530 mm
Height: 3840 mm
Weight: 6800 kg
Conveyor Dimensions: 710 x 2100
Material: Steel Pipe
Material Type: 10mm ST37
Transfer System: Shaft and Reducter
Pull Type: Pull Type
RPM: 540 d/dk
Required Tractor Power: 95-105 HP
Number of Blades: 18
Blade Type: Special Form
Helix Diameter: 2370 mm
Helix Rotation Cycle: 33,5 per minute
Side Sheet Thickness: 7 mm
Base Sheet Thickness: 25 mm
Length: 7800 mm
Width: 2530 mm
Height: 3840 mm
Weight: 6800 kg
Conveyor Dimensions: 710 x 2100
Material: Steel Pipe
Material Type: 10mm ST37
Transfer System: Shaft and Reducter
Pull Type: Pull Type
RPM: 540 d/dk
Required Tractor Power: 95-105 HP
Number of Blades: 18
Blade Type: Special Form
Helix Diameter: 2370 mm
Helix Rotation Cycle: 33,5 per minute
Side Sheet Thickness: 7 mm
Base Sheet Thickness: 25 mm
