Wheeled mini dumper EB500

electric

Product overview
The EB500 BENDie is an electric articulated mini dumper (4x4) designed for versatile material handling in confined sites. It features regenerative braking to extend operating range, quiet operation for noise-sensitive environments and a compact chassis that fits through standard doorways (3 ft for EB500).

Advantages

• Regenerative-braking system that returns energy to the battery
• Quiet operation for use in noise-restricted areas
• Compact, well-balanced design fits through typical doorways (2 ft 6 in EB400 / 3 ft EB500)
• Easy to transport and store between sites
• Patented steering pivot drive for excellent manoeuvrability
• Large 500 kg (or 400 kg) skip capacity with flotation tyres as standard
• Heavy-duty construction suitable for varied materials and rough terrain
• Fail-safe dead-man brake for operator safety
• 4x4 drive system for traction on gradients up to 25°
• Centre lifting point with locking pivot for safe lifting and transport
• 24-month battery warranty

Specifications
Model: Battery EB500 (4x4)
Motor / Power (kW): DC motor 2 x 750 W / 24 V
Power type: 2 x 12 V AGM batteries
Max payload: 500 kg / 1100 lbs / 12 ft³ / 0.35 m³
Unladen weight: 240 kg / 529 lbs
Working width: 850 mm
Working gradient: 25°
Drive & controls: 2 x 24 V transaxle (4x4 drive system)
Brake system: Electrically operated with fail-safe dead-man handle
Standard tyres: Flotation tyres (option: turf tyres)
Forward / reverse speed: 0–3.5 mph (5.63 km/h) forward; 0–1.5 mph (2.42 km/h) reverse
Noise level: < 76 dB
Hand-arm vibration: < 2.5 m/s²
Skip options: Poly or steel (steel 400 narrow)
Skip tipping: Gravity tip, Power-Tip & Power-Tip+
Compatible attachments: Tow ball hitch; snow plough (incl. tool bar 73-1000); steel and poly skip extensions; flatbeds

Technical details

• Model: EB500 BENDie (Battery EB500 4x4)
• Max payload: 500 kg
• Unladen weight: 240 kg
• Motor: DC motor 2 x 750 W / 24 V
• Batteries: 2 x 12 V AGM
• Drive: 4x4 (2 x 24 V transaxle)
• Top forward speed: up to 3.5 mph (5.63 km/h)
• Working width: 850 mm
• Working gradient: 25°
• Noise level: < 76 dB
• Battery warranty: 24 months
