Straight snow plow 5118

Product Overview The Universal divided snow plow is a robust and versatile municipal machine designed for efficient snow removal. It is available in several working widths and is equipped with advanced features for optimal performance in various conditions.

Standard equipment

• 3-point linkage cat. II
• Mouldboard height: 90.0/83.0 cm
• Mouldboard turning angle (right and left) up to 30°
• Mouldboard hydraulic control – two cylinders
• Side ground copying system at the hitch frame in the range of: lateral tilt +/- 5⁰
• Blade spring protection
• 50 mm rubber strip
• LED lights

Optional equipment

• Skids
• 160/50 or 200/50 support wheels
• Blade made of 150 x 16 mm wear-resistant steel
• 150 x 25 mm polyurethane blade
• Hydraulic overload protection
• 3-point-linkage cat. II and III or EURO mount and 3-point linkage cat. II
• Other type of mount for mini loaders or front loaders
• Other type of mount for telescopic loaders

Technical Specifications
Ref.No. | Working width [m] | Length/width/height [m] | Weight [kg]
5118 | 2.2 | 1.2 / 2.2 / 0.9 | 380
5119 | 2.5 | 1.2 / 2.5 / 0.9 | 400
5120 | 2.7 | 1.2 / 2.7 / 0.9 | 440
5121 | 3.0 | 1.2 / 3.0 / 0.9 | 480

Product numbers

• 5118
• 5119
• 5120
• 5121

Categories

• Municipal machines
• Snow ploughs/plows

Key Features / Technical Specifications

• Available working widths: 2.2 m, 2.5 m, 2.7 m, 3.0 m
• Length/width/height (m): 1.2 / 2.2 / 0.9 to 1.2 / 3.0 / 0.9
• Weight: 380 kg to 480 kg depending on model
• Mouldboard hydraulic control with two cylinders
• Side ground copying system with lateral tilt +/- 5⁰
• Blade spring protection and 50 mm rubber strip
• LED lighting for enhanced visibility
