Tandem axle slurry tanker ULTRACIS 1200

pressuretowedwith injector

Designed to offer an alternative for farm operators who need extra slurry spreading capacity at peak times, but need to keep an eye on costs. ULTRACIS series have self-supporting galvanized tanks with baffles for maximum stability. The vehicle axle and drawbar are connected by two sturdy longitudinal reinforcements, which also carry all supply lines (air, oil, electricity) and protect them from mechanical damage. The drawbar height can be adjusted among several levels. By swivelling the drawbar, it can be switched from clevis to hitch coupling as a standard feature. Hydraulic drawbar suspension is available as an option. HIGHLIGHTS CHASSIS Integrated chassis frame, fully galvanized, drawbar with height adjustment device (low and high mounting), drawbar eye D40, stable underrun protection with integrated lighting and turn signal, parking brake, reinforced parking jack with gearbox and dual drive AXLE Two heavy duty ADR-axles with 10-stud rims, track 1950 mm, wheelbase 1480 mm, axle load 14000 kg/axle, brake cam 406 x 120 mm BARREL BODY Fully galvanized barrel body with wall thickness 6 mm, wheel cut-out for wide tires, integrated baffle, connections for suction and discharge lines with quick coupler, slurry shovel with hydraulic actuation, level indicator, dome valve and siphon with sight glass, manhole cover at the rear, hose restraints left and right, manometer COMPRESSOR JUROP PN 106 with overpressure safety valve, flow rate at atm. pressure 11000 l/min, max. overpressure 1.0 bar, power requirement 13.6 kW
