Grain conveyor 0806

fertilizerbeltmobile

Overview
KSi seed and grain handling conveyors designed for gentle, efficient transfer in seed treatment and bin-filling operations. Patented cleated belt retains material on steep inclines and is offered in models 0806, 1208, 1610 and 1612 to cover a range of throughputs.

Key Features

• Model range: 0806, 1208, 1610, 1612 to match different capacity needs.
• Patented cleated belt: enables reliable material retention and flow on inclines up to 40°.
• High throughput: capacities approximately 1,000 to 5,000 bushels per hour depending on model.
• Drive flexibility: electric, PTO or hydraulic drive options to suit farm and processing setups.
• Lift and hopper options: cable or hydraulic lift; collapsible canvas hopper standard, galvanized hopper optional.

Operation & Features

• Simple loading: standard collapsible canvas hopper for easy handling and quick changeover.
• Top-drive design: patented top-drive reduces wear and simplifies operation.
• Service access: clean-out door and accessible components for fast commodity changes and routine maintenance.

Key Benefits

• Gentle handling: cleated belt minimizes seed damage during transfer.
• Adaptable use: suitable for seed treatment systems, bin filling and multi-commodity handling.
• Operator safety: shields and guards protect personnel during operation.
• Robust construction: galvanized tube with enclosed return increases service life in agricultural environments.

Product Gallery (examples)

• Close-up images of KSi patented cleated belt and cleat profile.
• Model examples including 1212, 1208 and 0806; wagon-mount and self-contained transfer (SCT) layouts; bin-fill setups with telescoping fill spouts.

Technical specifications

• Model dimensions: 0806 — 6" galvanized tube, 8" cleated belt; 1208 — 8" tube, 12" belt; 1610 — 10" tube, 16" belt; 1612 — 12" tube, 16" belt.
• Belt speed and incline: typical belt speed 376 ft/min; maximum incline up to 40°.
• Performance (approx.): 0806 — 1,000 BPH; 1208 — 2,000 BPH; 1610 — 4,500 BPH; 1612 — 5,000 BPH.
• Options: drive — electric / PTO / hydraulic; lift — cable or hydraulic; hopper — collapsible canvas (standard) or galvanized (optional); stainless steel available for fertilizer handling.
• Other variants: 1212 Inclinator (approx. 2,000 BPH, 30° max, 32' max length); SCT portable/self-contained models and adjustable telescoping fill spouts.
