Grain conveyor 12UC Undercar

beltflexiblehydraulic

Overview
Specialized undercar conveyors designed for efficient material handling beneath rail cars and trucks. Featuring durable construction and flexible drive options, these conveyors provide reliable performance in demanding undercar applications.

Key Features

• Versatile drive options: electric, hydraulic, or Honda motor configurations to match power requirements.
• Durable belt construction: 12" and 16" crescent rubber belting designed for reliable material transport.
• Compact design engineered for undercar applications with optimal space utilization.
• High-capacity performance delivering up to 4,000 bu/hr under normal operating conditions (model dependent).

Drive Options

• Electric Drive: Standard electric motor options for reliable, consistent power delivery.
• Hydraulic Drive: Hydraulic motor options for flexible installation and remote power source capability.
• Honda Engine: Gas-powered Honda engine option for portable and independent operation.

Product Gallery

• Multiple high-resolution product and application images showing overall system, installation, configuration, detailed views, and application in agricultural settings.

Documentation & Resources

• Comprehensive documentation is available including a product brochure and model-specific manuals covering specifications, operation, and technical guidance.

Model Specifications

• 12UC Model — Normal Capacity: 2,000 bu/hr. Drive Unit Options: Electric Motor 3 HP, 1725 RPM; Hydraulic Motor 4.8 cu.in/rev, 2000 PSI, 9 GPM; Honda Motor 5.5 HP. Belt: 12 in crescent rubber belting.
• 16UC Model — Normal Capacity: 4,000 bu/hr. Drive Unit Options: Electric Motor 5 HP, 1725 RPM; Hydraulic Motor 4.8 cu.in/rev. Belt: 16 in crescent rubber belting; Speed: 600 FPM. Weight with 3PH motor: 11 lbs.

Characteristics / Specifications techniques

• Models: 12UC and 16UC undercar conveyors.
• Normal capacities: 12UC — 2,000 bu/hr; 16UC — 4,000 bu/hr (under normal operating conditions; actual capacity depends on belt speed, angle, commodity, moisture, foreign matter, and feeding methods).
• Belt width and material: 12 in (12UC) and 16 in (16UC) crescent rubber belting.
• Belt speed: 16UC listed at 600 FPM (user-adjustable settings affect capacity).
• Electric motor options: 12UC — 3 HP, 1725 RPM; 16UC — 5 HP, 1725 RPM.
• Hydraulic motor option: 4.8 cu.in/rev (12UC includes specification 2000 PSI, 9 GPM example).
• Honda engine option: 5.5 HP available for portable operation (12UC example).
• Compact, space-optimized design for undercar installations.
• Listed weight (with 3PH motor): 11 lbs.
