Disc chain harrow XR series

with rollercombined

Overview
The CULTILINE XR is a mounted tillage tool with two rows of serrated discs, designed for high-speed combined work. Available in 3.00 m, 3.50 m and 4.00 m versions and compatible with XEOS units.

Features

• Two rows of 415 mm-diameter X-shaped serrated discs for effective mulch work at speed.
• High work rates: suitable for 12–15 km/h operation; up to 3.5 ha/h (XR 3000).
• Reinforced steel chassis and modular mounting for easy combination with seeding units.

Running costs
Operates without PTO and at low engine speeds to maximize fuel savings. The XR reduces implementation costs compared with animated tools.

Seedbed preparation
Soil flow is levelled by a comb harrow located behind the disc rows, then reconsolidated by a choice of rollers (Packer Ø 550, Gravity Ø 520 or Tracker Ø 550) before seeding.

Versatility
Designed for modular use: Xeos TF and Progress can be combined with the XR module or a SKY HR power harrow to support operations from first sowings through the season, including wet conditions.

Technical data
TYPE | XR 3000 | XR 3500 | XR 4000
Working width | 3.00 m | 3.50 m | 4.00 m
Number of disc rows | 2 | 2 | 2
Number of discs | 22 | 26 | 30
Disc type | Serrated Niaux 200 | Serrated Niaux 200 | Serrated Niaux 200
Recommended power (with XEOS Pro) | 150-210 hp | 175-240 hp | 220-300 hp
Weight Packer roller Ø 550 mm | 1441 kg | 1620 kg | 1816 kg
Roller weight Tracker Ø 550 mm spacing 150 mm | 1587 kg | 1806 kg | 2023 kg
Roller weight Gravity Ø 520 mm | 1420 kg | 1527 kg | 1723 kg

Characteristics / specifications

• Model variants: XR 3000, XR 3500, XR 4000.
• Working widths: 3.00 m / 3.50 m / 4.00 m.
• Disc diameter/design: 415 mm X-shaped serrated discs for high-speed mulch work.
• Recommended power ranges when combined with XEOS Pro (see table).
• Roller options for reconsolidation: Packer 550, Gravity Ø 520, Tracker Ø 550 (weights by model shown above).
