Tine harrow VR series

with roller

Overview
The VR is a three-row mounted tillage tool for seedbed preparation. Available in working widths 3.00 m, 3.50 m and 4.00 m, it is compact and designed to operate at speeds above 12 km/h to deliver high work rates.

Features

• Three-row mounted tillage tool with vibrating straight tines (32 x 12)
• Available widths: 3.00 m / 3.50 m / 4.00 m
• Designed for operation at speeds above 12 km/h
• Option of X‑arranged 415 mm discs for mulch work at 12–15 km/h
• Roller options: cage Ø 500 mm, packer Ø 550 mm, Tracker Ø 550 mm

Advantages / Running costs

• Passive, low operating cost implement
• Suitable for light or well-prepared soils
• High field output at recommended speeds
• Three rows of tines for uniform soil working

Construction

• Double-beam support frame 100 x 100 x 6.3 mm for stability at speed
• One-piece towbar with side stays
• Maximum clearance with three rows of vibrating straight tines

Technical data (table)
TYPE | VR – Series 1000 – VR 3000 | VR – Series 1000 – VR 3500 | VR – Series 1000 – VR 4000
Working width | 3.00 m | 3.50 m | 4.00 m
Number of rows of teeth | 3 | 3 | 3
Number of teeth | 24 | 28 | 32
Tine type | Vibrating (32 x 12) | Vibrating (32 x 12) | Vibrating (32 x 12)
Power | 70-170 hp | 90-200 hp | 120-260 hp
Weight cage roller Ø 500 mm | 660 kg | 740 kg | 820 kg
Weight packer roller Ø 550 mm | 860 kg | 950 kg | 1040 kg
Weight Tracker roller Ø 550 mm | 1048 kg | 1181 kg | 1297 kg

Characteristics / technical specifications

• Model / series: VR (Series 1000)
• Working widths: 3.00 m, 3.50 m, 4.00 m
• Three rows of vibrating straight tines 32 x 12
• Number of teeth by width: 24 / 28 / 32
• Recommended tractor power: 70–170 hp (3.00 m) / 90–200 hp (3.50 m) / 120–260 hp (4.00 m)
• Roller options and weights as listed above
• Frame: double-beam 100 x 100 x 6.3 mm for high-speed stability
