Pruning harvest trolley

for horticultureself-propelledelectric drive

Description
Harvest collection cart length 2.8 m and width 1.70 m or 1.80 m
Fruit collection cart with an intuitive watertight electrical control panel, equipped with motor protector and hour counter. Protections to prevent damage from branches and impacts and to ensure lower noise levels and operator safety. Easily movable guide on guide slots. Large-capacity tanks without protruding parts or pipes. Equipped with elevators with swing, steering on 4 independent wheels with a self-aligning device, hydraulic rollers or chain conveyors. Fitted with accessories such as a pruning pole with convenient hooks, automatic guidance with hydraulic adjustment and removable USB radio.

Optional

• Device for digital and precision agriculture with satellite tracking and remote parameter monitoring
• Engine hours counter
• Counting of bins discharged with the rear elevator, with discharge position displayed on a map
• Detection of the vehicle within a set geographic perimeter (geofencing)
• Remote on/off of compressor and automatic guidance

Information (table extract)
Harvest collection cart length 2.8 m and width 1.70 m or 1.80 m
48 V electric traction with 420 Ah lead battery, available with 3 kW single-phase (220 V) or three-phase (380 V) charger. Electric transmission with mechanical 2-speed gearbox and removable battery. Estimated recharge time: 7 hours. Standard device for remote monitoring of battery consumption and state of charge.
Yanmar 1400 cc 30 HP direct injection engine for lower consumption and torque at low revs; hydrostatic transmission with 28 cc piston pump, 2-speed electrohydraulic gearbox for on-the-move gear changes and negative parking brake.

Technical features of the various models (table extract)
1400 cc direct injection engine mounted on balanced springs to reduce vibrations
Negative parking brake
Available in lengths: 2.5 - 2.8 - 3.5 - 4.0 m; widths: 1.50 - 1.70 - 1.80 m
Ultra-flat platform without steps
Available with 4-wheel drive and 2 or 4 self-aligning steering wheels
Maximum height 2.95 m
Compressor 500 or 650 l with electrohydraulic drive and 45 l air reservoir
Ultra-compact foldable elevators
2-speed electrohydraulic gearbox for under-load gear changes via switch on the steering column

Technical specifications / Characteristics

• Length: 2.8 m (indicated variant; other lengths available 2.5 / 3.5 / 4.0 m)
• Width: 1.70 m or 1.80 m (other widths available 1.50 m)
• Traction: 48 V, 420 Ah lead battery; 3 kW single-phase or three-phase charger; removable battery; estimated recharge time 7 hours
• Electric transmission: mechanical 2-speed gearbox
• Engine (thermal version): Yanmar 1400 cc, 30 HP, direct injection; hydrostatic transmission with 28 cc piston pump
• Steering: steering on 4 independent wheels with self-aligning device; available 2 or 4 self-aligning steering wheels
• Platform: ultra-flat without steps
• Maximum height: 2.95 m
• Compressor: 500 or 650 l with electrohydraulic drive; 45 l air reserve
• Elevators: ultra-compact and foldable; elevators with swing
• Safety: anti-impact and anti-branch protections; motor protector; hour counter
• Accessories: pruning pole with hooks, automatic guidance with hydraulic adjustment, removable USB radio
• Digital optional: satellite tracking, remote parameter monitoring, bins counting, geofencing, remote control of compressor and automatic guidance
