Orchard harvest trolley

self-propelledadjustable-heightelectric

Description
Fruit collection cart length 4.00 m and width 1.70 m or 1.80 m
Purpose-built cart for harvesting and transporting fruit in orchard operations. Available in electric drive (48 V battery) or diesel-assisted versions. Control panel includes motor protection and hour counter. Structural protections reduce damage from branches and impacts while improving operator safety. Movable steering column on slotted guides for ergonomic adjustment. Large-capacity tanks designed without protruding pipes.

Key features

• Elevators with lateral articulation
• Four-wheel steering with self-alignment (available)
• Floor conveyors: rollers or hydraulic chain conveyors
• Accessories: pruning pole with hooks, hydraulically adjustable automatic guidance, removable USB radio

Optional

• Precision agriculture device with satellite tracking and remote parameter monitoring
• Engine hour counter
• Bin discharge counter with rear elevator and mapped discharge positions
• Geofencing detection (vehicle inside a set perimeter)
• Remote on/off for compressor and automatic guidance

Specifications (table)
Length 4.00 m; width 1.70 m or 1.80 m
Electric traction 48 V with 420 Ah lead battery, available with 3 kW charger (single-phase 220 V or three-phase 380 V). Electric transmission with 2-speed mechanical gearbox; removable battery. Estimated charging time: 7 hours. Standard remote monitoring for battery charge and consumption.
Alternative powertrain: Yanmar 1,400 cc diesel, 30 hp, direct injection; hydrostatic transmission with 28 cc piston pump and 2-speed electro-hydraulic gear change for on-the-move shifts; negative parking brake.

Additional information (table)
Chassis dimensions: 4.00 x 1.80 m or 1.70 m
Maximum height: 2.95 m
Drive: 2- or 4-wheel drive; steering: 2 or 4 steered wheels
2-speed electro-hydraulic gearbox for on-the-move gear change
Negative parking brake
Movable steering column on slotted guides
Step-free platform with 80 cm hydraulic opening per side, pedal-operated on the front of the platform
Compressor: 500 or 650 L with electro-hydraulic drive and 50 L air reserve
Rollers on the loading floor
Front tips or front/rear elevators available
Side covers for accessory protection
Wheels: 10.0/75-15.3 or 31/15.50-15
CE certification issued by a qualified engineer

Characteristics / technical specifications

• Model: Fruit collection cart
• Length: 4.00 m (width 1.70 m or 1.80 m)
• Electric traction: 48 V with 420 Ah battery and 3 kW charger (single- or three-phase)
• Alternative engine: Yanmar 1,400 cc 30 HP
• Transmission: electric with 2-speed mechanical gearbox or hydrostatic with 28 cc piston pump (depending on version)
• Steering: 2 or 4 steered wheels; self-alignment on 4 independent wheels (version-specific)
• Maximum height: 2.95 m
• Platform: 80 cm opening per side, hydraulic pedal control
• Compressor: 500 or 650 L with 50 L air reserve
• Wheels: 10.0/75-15.3 or 31/15.50-15
• Accessories: pruning pole with hooks, hydraulically adjustable automatic guidance, removable USB radio, articulated elevators, roller or hydraulic chain conveyors
• Certification: CE
