Disc harrow with roller Simply 220

Disc harrow with roller - Simply 220 - Tolmet
Disc harrow with roller - Simply 220 - Tolmet
Add to favorites
Compare this product

Characteristics

Other characteristic
with roller
Width

Min.: 2.2 m
(7'02" )

Max.: 3 m
(9'10" )

Description

Standard equipment: - Two rows of discs with rubber shock absorption - 510 mm diameter discs with maintenance-free hubs with seals - Rear, tubular roller with bearing (self-aligning ball bearing UCF 208) Ø 510 mm or string roller Ø 440 mm - Automatic draw bar - Disc track 800 mm - Two baskets for weights Optional equipment: - Side screens - Levelling scraper - Ring roller Ø 500 mm - Route lights Model specifications: Simply 220: 2.2 m width, 18 discs, 850 kg, 65-75 HP Simply 250: 2.5 m width, 20 discs, 900 kg, 70-80 HP Simply 270: 2.7 m width, 22 discs, 950 kg, 75-95 HP Simply 300: 3.0 m width, 24 discs, 1000 kg, 90-100 HP Information about the rollers: Simply 220-300: - Tubular Ø 510 mm ✔ - String Ø 440 mm ✔ - Ring Ø 500 mm ✔ Technical characteristics / specifications: - Working width: 2.2 m, 2.5 m, 2.7 m, 3.0 m - Number of discs: 18 (2.2 m), 20 (2.5 m), 22 (2.7 m), 24 (3.0 m) - Weight (kg): 850 (2.2 m), 900 (2.5 m), 950 (2.7 m), 1000 (3.0 m) - Required power (HP): 65-75 (2.2 m), 70-80 (2.5 m), 75-95 (2.7 m), 90-100 (3.0 m) - Available rollers: Tubular Ø 510 mm, String Ø 440 mm, Ring Ø 500 mm
