Mounted bale unroller DR 180 I PIC

feedinground

Overview
DR 180 PIC – DR 180 I PIC: 2-in-1 solution for handling and distributing round bales with a front loader or telehandler. Allows switching between handling and distribution without changing equipment.

Handling and unrolling
Equipped with a bale spike for handling and loading round bales, the DR 180 PIC provides straightforward unrolling. The DR 180 I PIC features a tilting box that controls bale position and enables unrolling down to the core.

Key features

• Bale spike: Accessory for handling round and square bales; fitted with 2 spikes 150 cm long, Ø40 mm, with 90 cm spacing between spikes.
• Direct drive: The unroller includes an automatic locking system that secures the unit once raised.
• Automatic coupling: Automatic locking mechanism ensuring safe and secure positioning when set in place.
• Left or right distribution: Can be attached to one side or both sides to allow left or right distribution (optional).
• Tilting box (DR 180 I PIC): Controls bale position and allows full unrolling to the core.
• Loading arm: Available as an option or as factory-fitted depending on model (manual or integrated).

Available options and equipment

• Retractable spikes: optional.
• Sheet-metal floor: optional.
• Electric control: optional.
• 3-point hitch / telescopic hitch: depending on version, 3-point hitch or telescopic hitch available (options/versions).
• Hydraulic function: depending on version (e.g., 2 double-acting outlets in some configurations).

Technical specifications

• DR 180 PIC: Round bales: Ø 1.80 m max
  Distribution: Front left
  Overall height (mm): 1260
  Overall length (mm): 1900
  Overall width (mm): 2280
  Hydraulic flow required: 40–50 l/min
  Tractor power (HP): 100
  Unladen weight (kg): 750
  Loading arm: optional (manual)
  Retractable spikes: optional
  Sheet-metal floor: optional
  Electric control: optional
  3-point hitch: optional
  Telescopic hitch: optional
• DR 180 I PIC: Round bales: Ø 1.80 m max
  Distribution: Front left
  Overall height (mm): 1260
  Overall length (mm): 1900
  Overall width (mm): 2280
  Hydraulic function: 2 double-acting outlets (depending on configuration)
  Hydraulic flow required: 40–50 l/min
  Tractor power (HP): 100
  Unladen weight (kg): 750
  Loading arm: yes (factory-fitted version)
  Retractable spikes: optional
  Sheet-metal floor: optional
  Electric control: optional
  3-point hitch: yes (depending on version)
  Telescopic hitch: optional
