Vertical mixing wagon

mountedrear dischargewith weighing system

Product Overview
The 5 m³ Vertical Vehicle-Mounted TMR Mixer is a vehicle-mounted vertical total mixed ration (TMR) mixer designed for mobile feeding operations on livestock farms. It mixes forage, silage, concentrates and other compatible feed materials into a uniform ration for daily feeding and distribution.

Key Features and Advantages

• Vertical TMR mixing configuration optimized for on-the-move ration preparation.
• Dimensions and configuration based on supplied specification file for the 5 m³ model.
• Capable of mixing, loading, hydraulic rear discharge and feeding support according to model configuration.

Technical Specifications
Model — 5 m³ Vertical Vehicle-Mounted TMR Mixer
Overall Dimensions (L × W × H) — 4800 × 2200 × 2300 mm
Top Opening Length — 2800 mm
Machine Weight — 2400 kg
Main Shaft Speed — 23 r/min
Reducer — Vertical reduction gearbox
Production Capacity — 3 t/h
Chassis — Original Wuzheng three-wheel chassis; Manufacturer: Xiangyunhu
Triangle Blades — Tungsten carbide, 5 pcs
Weighing Sensors — 4 pcs
Weighing Indicator — XK3190-A6
Loading Port Height — 80 cm
Rear Loading — Hydraulic control
Plate Thickness — bottom plate 12 mm, side plate 6 mm; auger 12 mm

Applications

• Livestock farms
• Cattle and sheep feed preparation
• Total mixed ration production and distribution
• Daily feeding and feed distribution support

Specifications / Technical Data

• Model: 5 m³ Vertical Vehicle-Mounted TMR Mixer
• Overall Dimensions (L × W × H): 4800 × 2200 × 2300 mm
• Top Opening Length: 2800 mm
• Production Capacity: 3 t/h
• Machine Weight: 2400 kg
• Main Shaft Speed: 23 r/min
• Reducer: Vertical reduction gearbox
• Chassis: Original Wuzheng three-wheel chassis; Manufacturer: Xiangyunhu
• Triangle Blades: Tungsten carbide, 5 pcs
• Weighing Sensors: 4 pcs
• Weighing Indicator: XK3190-A6
• Loading Port Height: 80 cm
• Rear Loading: Hydraulic control
• Plate Thickness: bottom plate 12 mm, side plate 6 mm; auger 12 mm
