Vertical mixing wagon 9JGL-12

towedwith weighing system

Product Overview
The 12 m³ Vertical Electric Total Mixed Ration (TMR) Mixer 9JGL-12 is a fixed vertical feed mixer engineered for on-farm production of uniform rations. Its electric drive and multi-blade auger deliver consistent blending of forage, silage and concentrates for daily feeding operations.

Key Features and Advantages

• Fixed vertical TMR configuration for stable, repeatable mixing performance.
• 37 kW matched power suitable for continuous farm use.
• Mixing system with triangle, small and fixed blades for efficient particle breakdown and uniformity.
• Integrated weighing system (1 set) for accurate batch formulation and traceability.
• Single discharge outlet with 1.5 kW motor for controlled unloading and feeding integration.

Dimensions and Power
Overall Dimensions (L × W × H): 4000 × 2250 × 2700 mm
Hopper Volume: 12 m³
Matched Power: 37 kW
Main Shaft Speed: 23 r/min

Technical Specifications

• Product Name: Total Mixed Ration Feed Mixer
• Model: 9JGL-12
• Structure Type: Fixed vertical
• Blade Material: Cr12MoV
• Steel Plate Material: QB345
• Hopper Steel Plate Thickness: 8 mm; Bottom Plate Thickness: 20 mm; Auger Plate Thickness: 16 mm
• Weighing System: 1 set
• Number of Discharge Outlets: 1
• Discharge Outlet Motor: 1.5 kW

Applications

• Livestock farms (dairy, beef, sheep)
• Cattle and sheep feed preparation and TMR processing
• Daily feeding operations and feed distribution
• Integration with feed batching and farm automation systems

Technical Characteristics

• Hopper Volume: 12 m³
• Overall Dimensions (L × W × H): 4000 × 2250 × 2700 mm
• Matched Power: 37 kW
• Main Shaft Speed: 23 r/min
• Blade Quantity: triangle blades, small blades, fixed blades (pcs)
• Materials: Blade Cr12MoV; Steel QB345
• Plate Thicknesses: Hopper 8 mm; Bottom 20 mm; Auger 16 mm
