Vertical mixing wagon 9JQL-9

towedwith weighing systemPTO-driven

Product Overview
The 9 m³ Vertical PTO TMR Mixer 9JQL-9 is a trailed, tractor PTO-driven total mixed ration (TMR) mixer designed for on-farm feed preparation and daily ration distribution. It mixes forage, silage and concentrates into a homogeneous feed to support livestock feeding operations.

Key Features and Advantages

• Vertical TMR mixing configuration for efficient homogenization of feed components.
• Design and dimensions based on supplied specification file for predictable farm integration.
• Suitable for mixing, loading, discharge and feeding-support tasks depending on selected model options.

Basic Data
Overall Dimensions (L x W x H): 4200 × 2300 × 2600 mm
Mixing Chamber Volume: 9 m³
Matched Power: 70 HP or above
Matched Power Type: Tractor rear PTO power

Applications

• Livestock farms
• Cattle and sheep feed preparation
• Total mixed ration processing
• Daily feeding and feed distribution support

Technical specifications

• Model: 9JQL-9 Total Mixed Ration Feed Mixer
• Mixing Chamber Volume: 9 m³
• Structure Type: Vertical trailed type
• Overall Dimensions (L x W x H): 4200 × 2300 × 2600 mm
• Matched Power Type: Tractor rear PTO power
• Matched Power: 70 HP or above
• Number of Main Shafts: 1 pcs
• Main Shaft Speed: 23 r/min
• Blade Quantity: large blades 7, small blades 5 pcs
• Blade Material: Cr12MoV
• Weighing System: 1 set
• Production Efficiency: 3000-4000 Kg/h
• Number of Discharge Outlets: 1 pcs
