Vertical mixing wagon 9JQL-12

towedwith weighing systemPTO-driven

Product Overview
The 12 m³ vertical PTO TMR mixer is a tractor PTO-driven vertical total mixed ration (TMR) feed mixer designed for on-farm preparation of uniform livestock rations. It mixes forage, silage and concentrates and supports loading, weighing and discharge operations adapted to daily feeding workflows.

Key Features and Advantages

• Vertical TMR mixing configuration for homogeneous feed distribution.
• Designed for tractor rear PTO drive; matched power requirement >50 HP.
• Blades and hopper manufactured from specified materials: Cr12MoV blades and QB345 steel plates with defined thicknesses.
• Integrated weighing system and a single discharge outlet for controlled portioning and feeding.

Technical Specifications

• Product Name: Total Mixed Ration Feed Mixer
• Model: 9JQL-12
• Hopper Volume: 12 m³
• Matched Power Type: Tractor rear PTO power
• Matched Power: >50 HP
• Overall Dimensions (L x W x H): 4300×2300×2700 mm
• Main Shaft Speed: 23 r/min
• Blade Quantity: triangle blades 8; small blades 6; fixed blades 2 pcs
• Blade Material: Cr12MoV
• Steel Plate Material: QB345
• Hopper Steel Plate Thickness: 8 mm
• Hopper Bottom Plate Thickness: 20 mm
• Weighing System: 1 set
• Number of Discharge Outlets: 1 pcs
• Tire Model: 6.50-16
• Tire Quantity: 4 pcs

Applications

• Livestock farms
• Cattle and sheep feed preparation
• Total mixed ration processing and blending
• Daily feeding and feed distribution support
