Grain mill 1240

for animal feedbarleyflake

Overview The Wakely 1240 Compact is designed for large farmers and contractors to roll, crimp or flake high volumes of dry grain quickly. Available in contractor/mobile, electric industrial and grain treatment configurations, the 1240 supports continuous on-farm, mobile and industrial operations.

Key benefits

• Uses at least 50% less electricity than typical hammer mills due to a one-pass grinding system.
• No screen changes required: roll-gap adjustment provides instant grist changes from coarse to fine.
• Minimal heat generation: processed grain remains cool, reducing thermal damage to the product.
• Reduced dust generation compared with multi-pass systems, lowering hazardous fine particles and improving safety.

Performance and capability

• Example output: 13.0 t/h barley at 12% moisture producing a finely ground sample (~0.8 μm or less).
• Example output: 22.0 t/h barley at 12% moisture producing a coarsely ground sample (~1.2 μm).
• Industrial configurations cover approximately 8–20 t/h and can be set up to grind, crimp or roll to specified particle sizes.

Design & construction highlights

• Fluted solid chilled rolls (1200 x 400 mm) for consistent, long-life performance.
• Heavy-duty components and double-row spherical bearings housed in robust plummer blocks.
• One-touch operator controls for straightforward adjustment and operation.
• Can integrate with rubble separators, magnet tables, pin feeders, augers, conveyors and treatment or bagging systems.

Applications Targeted at contractors, large arable farmers and feed compounders requiring a reliable, efficient, low-maintenance high-capacity roller mill for continuous industrial or mobile use.

Some of our clients GLANBIA; Centenary Thurles Co-op; Platin Grain; Hyde Feeds.

Technical specifications

• Model / series: Wakely 1240 (contractor/mobile, electric grain mill, grain treatment mill).
• Rolls: Fluted solid chilled rolls, 1200 x 400 mm.
• Bearings: Double-row spherical bearings in heavy-duty plummer blocks.
• Operator controls: One-touch operator controls.
• Weight: 4,500 kg.
• Overall size (approx): L 4930 x W 1945 x H 1500 mm.
• Typical outputs: 13.0 t/h (finely ground, ~0.8 μm); 22.0 t/h (coarsely ground, ~1.2 μm).
• Industrial capacity range: ~8–20 t/h depending on configuration.
• Options/add-ons: rubble separators, magnet tables, pin feeders, augers, conveyors, treatment systems, bagging options.
