Right hand vine binder F3X series

wirefor viticultureelectric

Overview
Designed for viticulture professionals, the F3X-V25 and F3X-H35 ambidextrous electric tying tools are the 4th generation of equipment combining performance, user ergonomics and durability. The design improves field efficiency while reducing strain during prolonged use.

Models
F3X-V25: 25 mm hooked opening, suited to fast, close ties commonly used in vineyards.
F3X-H35: 35 mm horizontal opening, for thicker branches, trellis structures, irrigation lines and planters.

Spools and autonomy
Both models use the ALPHA LITE on-board battery, offering up to 13,000 ties per charge.

• 80 m on-board spool: up to 600 ties (F3X-V25) and 480 ties (F3X-H35) — increased freedom of movement in the field.
• 200 m belt spool: up to 1,500 ties (F3X-V25) and 1,200 ties (F3X-H35) — recommended to maximise productivity during long tying sessions.

Availability
F3X tying tools available in autumn 2025.

Benefits and key features

• Lightweight, balanced electric tying tools — comfortable handling (F3X-V25: 845 g; F3X-H35: 850 g with on-board battery).
• Electronic trigger and comfort grip designed to reduce musculoskeletal strain during long working days.
• On-board spool option for optimum freedom of movement.

Productivity and performance

• Tying rate up to 120 ties per minute and up to 13,000 ties per battery charge.
• Optimised spool replacement to maintain a high work rate.
• Up to 1,500 ties with 200 m spool and up to 600 ties with 80 m spool.

Precise tying

• Eight twist levels to suit different plantation types, varieties and growth stages.
• Adjustable tightening to protect bark and young branches (1.5 to 12 turns).
• Secure plant support without injury.

Connected features
Configure and monitor the tying tools from the PELLENC CONNECT LITE app:

• Set tie parameters
• View performance and tool status
• Receive maintenance warnings
• Simplify fleet management

Types of ties available
Four tie types adapt to crop needs, climate and required lifespan:

• Paper — degradation 6–9 months; retains moisture to promote deterioration and facilitate release by woody growth.
• Climate — degradation 7–10 months; paper envelope with PLA (corn starch); biodegradable and reduces tool dust.
• Standard — degradation 10–12 months depending on weather; 0.44 mm steel wire; average tie strength ≈ 14 kg.
• Stainless steel — minimal degradation; for cordon vines, planters and irrigation lines; 0.44 mm stainless steel wire; average tie strength ≈ 14 kg.

Technical specifications

• Series / model: F3X (F3X-V25 and F3X-H35)
• Tying diameters: 25 mm (V25) and 35 mm (H35)
• Weight (with battery): 845 g (V25) / 850 g (H35)
• Tying rate: up to 120 ties per minute
• Battery life: up to 13,000 ties per charge (ALPHA LITE)
• Spool options: 80 m on-board (600 ties V25 / 480 ties H35) and 200 m belt (1,500 ties V25 / 1,200 ties H35)
• Tension / twist modes: 8 modes (1.5 to 12 turns)
• Connectivity: PELLENC CONNECT LITE app
• Battery: ALPHA LITE — 30.2 Wh, 10.8 V, 210 g, 1.5 h charge
• Origin: Made in France
• Warranty: 2 + 3 years

ALPHA LITE battery (summary)

• Compatibility: pruning shears C3X and tying tools F3X-V25 / F3X-H35
• Weight: 210 g
• Capacity: 30.2 Wh
• Voltage: 10.8 V
• Average battery life: pruning shears 2–4 h (3,000–4,000 cuts); tying tool: full working day — up to 13,000 ties
• Charging time (to 100%): 1.5 h with ALPHA LITE charger
• Winterising safety: yes

Accessories and consumables (overview)
Available accessories: 200 m belt spool (max 1,500 ties), 80 m on-board spool (max 600 ties), ALPHA LITE battery, carrying kit, 1- and 3-position chargers, portable USB-C charger, and the range of ties described above.
