Grain dryer TURBODRY

mobilegascontinuous

Overview
Direct-flame drying for high energy yield and reduced consumption. Born from deep knowledge of agricultural needs, TURBODRY dryers are designed for direct-flame grain drying with models differing by size, power and maximum production capacity. Units are configurable with construction variants to meet specific farm requirements.

Key benefits

• High energy efficiency through direct-flame drying and thermal optimization.
• Temperature stability ensured by a drying chamber lined with refractory material for more complete combustion and energy savings.
• Drying homogeneity achieved by continuous internal product movement for uniform drying and improved preservation.
• Fast drying enabled by a large heat exchange surface between hot air and product, allowing rapid drying without compromising quality.

Main components (visualizer)

• Loading auger: allows loading the product to be dried into the dryer bell.
• Central auger: transports the product upwards, reintroducing it into the drying area and later facilitating discharge of the dried product.
• Swivel discharge: dried grain can be discharged by gravity or, on flat ground, via an electric-motor auger ensuring a constant flow.
• Burner: heat source for drying. Standard equipment includes diesel burners; methane gas or LPG burners available on request.
• Fan: draws external air, channels it through the pre-heated furnace, and sends it into the bell to uniformly reduce grain moisture.
• Expulsion cleaner: removes impurities using a drop-expulsion mechanism, separating unwanted fractions from input or output product.
• Electrical panel (automatic/manual): centralized management of all dryer operations in automatic or manual mode.
• Drive (PTO and/or electric): mobile dryers are available with PTO (cardan), electric or mixed drive depending on operational needs.
• Sensors: temperature sensors measure and monitor product temperature during drying processes.

Models and technical data
Width 2.25 m
Model | Capacity m³ | PTO power HP (kW) | Electric power kW | Datasheet
AS 400 | 8 | 30 (22) | 17 |
AS 500 | 10 | 35 (26) | 17.5 |

Width 2.55 m
Model | Capacity m³ | PTO power HP (kW) | Electric power kW | Datasheet
AS 600 | 11.5 | 40 (30) | 21 |
AS 900 | 15 | 45 (34) | 25 |
AS 1000 | 17 | 50 (37) | 27 |
AS 1150 | 19 | 55 (41) | 31 |

Width 3.2 m
Model | Capacity m³ | PTO power HP (kW) | Electric power kW | Datasheet
AS 1350 | 21 | 65 (49) | 37 |
AS 1550 | 28.5 | 70 (52) | 39 |
AS 1750 | 32 | 75 (56) | 42 |

Width 4 m
Model | Capacity m³ | PTO power HP (kW) | Electric power kW | Datasheet
AS 2650 | 52 | 100 (75) | 55 |
AS 3150 | 58 | 110 (82) | 57 |
AS 3550 | 64 | 150 (112) | 85 |
AS 3750 | 75 | 150 (112) | 85 |

Characteristics / technical specifications

• Drying type: direct-flame drying (high energy yield, reduced consumption).
• Chamber lining: refractory material for temperature stabilization and improved combustion efficiency.
• Motion: continuous internal product movement for homogeneous drying.
• Heat exchange: large surface area for fast drying without quality loss.
• Burner options: standard diesel; methane gas or LPG available on request.
• Drive options: PTO (cardan), electric or mixed drive (mobile dryers).
• Control: electrical panel with automatic and manual operation modes.
• Sensors: temperature sensors to measure and monitor product temperature during drying.
• Available widths and model range: multiple widths (2.25 m, 2.55 m, 3.2 m, 4 m) with models AS 400 through AS 3750 covering capacities approx. 8–75 m³ and varying power requirements.
