Self-propelled manure spreader

single-axle

Product Overview
The Aoxiang 3 m³ chassis manure spreader is built for transport and uniform spreading of solid fertilizers. It features a self-powered three-wheel chassis, rear dual-disc spreading mechanism and a chain-board feeding system, suitable for manure, organic fertilizer, lime, distillers' grains, sugar residue and granular fertilizers.

Key Features and Advantages

• Three-wheel chassis with integrated power unit for independent field operation.
• Rear dual-disc spreading system for even lateral distribution across 6–12 m.
• Chain-board feeding delivers material from the box to the spreading unit.
• Semi-enclosed box with self-unloading tipping function for efficient discharge.
• Air brake and specified tire sizes for safe transport and stability.

Technical Specifications
Product Type: Semi-Enclosed Three-Wheel Dual-Disc Manure Spreader
Engine: Changchai 35 HP Water-Circulation Engine
Overall Dimensions: 5200 x 1950 x 2250 mm
Box Dimensions: 2570 × 1600/960 x 1350 mm
Box Volume: 3 m³
Maximum Load Capacity: 4000 kg
Spreading Device Type: Rear Dual Disc
Material Feeding System: Chain Board Pushing
Spreading Width: 6–12 m
Brake System: Air Brake
Tire Specifications: Front 650-16; Rear 700-16
Number of Tires: 5
Operating Method: Rear Spreading
Structure Type: Box Body with Self-Unloading Tipping Function

Applications

• Sized for livestock farms, arable fields, orchards, greenhouses and pastures.
• Compatible materials: manure, organic fertilizer, lime, distillers' grains, sugar residue, granular fertilizer.

Operation Instructions and Safety Notes

• Inspect chassis, tires, engine and spreading components before use.
• Do not exceed rated load; load materials evenly and secure for transport.
• Clear personnel and obstacles from the work area before engaging the spreading unit; adjust settings to material properties.
• Follow engine and brake maintenance schedules and check transmission parts regularly.

Maintenance Recommendations

• Remove residual fertilizer after each use to prevent corrosion and blockages.
• Regularly lubricate bearings and moving parts.
• Monitor wear parts (chain board, discs, bearings) and replace as needed.
• Store in a dry, ventilated area when not in use for extended periods.

Specifications

• Product Type: Semi-Enclosed Three-Wheel Dual-Disc Manure Spreader
• Engine: Changchai 35 HP Water-Circulation Engine
• Box Volume: 3 m³
• Overall Dimensions: 5200 x 1950 x 2250 mm
• Box Dimensions: 2570 × 1600/960 x 1350 mm
• Maximum Load Capacity: 4000 kg
• Spreading Width: 6–12 m
• Spreading Device: Rear Dual Disc
• Material Feeding System: Chain Board Pushing
• Brake System: Air Brake
• Tire Specs: Front 650-16; Rear 700-16
• Number of Tires: 5
• Operating Method: Rear Spreading
• Structure Type: Box Body with Self-Unloading Tipping Function
