Grain dryer TURBODRY AS 3550

mobilewheeled

Overview
Designed for agricultural use, TURBODRY dryers are mobile direct-flame grain dryers available in multiple widths and capacities. Models are configurable with different drive and burner options to suit on‑farm drying needs and operational constraints.

Compact efficiency — Key advantages

• Thermal optimization: Generated heat is directed onto the product to minimize losses and increase process energy efficiency.
• Temperature stability: Refractory-lined drying chamber stabilizes hot‑air temperature for more complete combustion and reduced fuel consumption.
• Drying homogeneity: Continuous internal product circulation ensures uniform moisture reduction and consistent grain quality.
• Fast drying: Large heat-exchange surface accelerates drying times without compromising product integrity.

Core components (visualizer items)

• Loading auger: Feeds product into the dryer bell.
• Central auger: Transports and redistributes product within the drying area and assists discharge.
• Swivel discharge: Allows gravity discharge or, on flat sites, motorized auger discharge for constant flow.
• Burner: Heat source; standard diesel burners. Methane gas or LPG burners available on request.
• Fan: Draws external air, channels it through the preheated furnace and distributes hot air into the bell.
• Expulsion cleaner: Removes impurities by drop-expulsion to separate unwanted fractions.
• Electrical panel (automatic/manual): Centralized control for automatic or manual operation.
• Drive (PTO and/or electric): PTO (cardan), electric or mixed drive options.
• Sensors: Temperature sensors for continuous monitoring during drying.

Models and technical tables
Width 2.25 m
Modello | Capacità m³ | Potenza Cardano HP (kW) | Potenza Elettrica kW
AS 400 | 8 | 30 (22) | 17
AS 500 | 10 | 35 (26) | 17.5

Width 2.55 m
Modello | Capacità m³ | Potenza Cardano HP (kW) | Potenza Elettrica kW
AS 600 | 11.5 | 40 (30) | 21
AS 900 | 15 | 45 (34) | 25
AS 1000 | 17 | 50 (37) | 27
AS 1150 | 19 | 55 (41) | 31

Width 3.2 m
Modello | Capacità m³ | Potenza Cardano HP (kW) | Potenza Elettrica kW
AS 1350 | 21 | 65 (49) | 37
AS 1550 | 28.5 | 70 (52) | 39
AS 1750 | 32 | 75 (56) | 42

Width 4 m
Modello | Capacità m³ | Potenza Cardano HP (kW) | Potenza Elettrica kW
AS 2250 | 44 | 100 (75) | 54
AS 2650 | 52 | 100 (75) | 55
AS 3150 | 58 | 110 (82) | 57
AS 3550 | 64 | 150 (112) | 85
AS 3750 | 75 | 150 (112) | 85

Technical specifications

• Drying method: Direct-flame drying for high thermal yield and reduced consumption.
• Heat management: Thermal optimization with refractory-lined chamber for temperature stability.
• Burners: Diesel standard; methane gas or LPG optional.
• Air handling: Dedicated fan for preheated air distribution into the drying bell.
• Material handling: Loading and central augers, swivel or motorized discharge for continuous flow.
• Cleaning: Expulsion cleaner to separate impurities.
• Control: Electrical panel with automatic and manual modes.
• Drive options: PTO, electric or mixed according to operational needs.
• Sensors & monitoring: Temperature sensors for product monitoring.
• Model range: Widths 2.25–4 m, capacities 8–75 m³ with corresponding PTO and electric power ratings as listed above.
