Grain dryer TURBODRY AS 600

cerealseedmobile

Product overview
Designed for agricultural use, the TURBODRY Series are mobile direct-flame grain dryers engineered for efficient, on‑site drying of cereals, legumes and seeds. Models vary by width, capacity and power and can be configured with burner and drive options to match farm requirements.

Compact efficiency — key advantages

• Thermal optimization — Generated heat is channeled directly to the product to minimize losses and improve energy yield.
• Temperature stability — Refractory-lined drying chamber stabilizes hot-air temperature for more complete combustion and consistent drying.
• Drying homogeneity — Continuous product circulation inside the dryer ensures uniform moisture reduction and better preservation.
• Fast drying — Large heat-exchange surface between hot air and grain enables reduced drying times without compromising product quality.

Core components (visualizer items)

• Loading auger — Feeds the product into the dryer bell for initial intake.
• Central auger — Transports product upward, reintroducing it into the drying zone and assisting discharge of dried product.
• Swivel discharge — Allows gravity discharge or, on level ground, motorized auger discharge for constant flow.
• Burner — Heat source for drying. Standard diesel burners; methane or LPG burners available on request.
• Fan — Draws external air through the preheated furnace into the bell to evenly reduce moisture.
• Expulsion cleaner — Removes impurities by drop-expulsion, separating unwanted fractions from input or output product.
• Electrical panel (automatic/manual) — Centralized control of dryer functions in automatic or manual mode.
• Drive (PTO and/or electric) — Mobile units available with PTO (cardan), electric or mixed drive depending on operational needs.
• Sensors — Temperature sensors for monitoring product temperature during drying cycles.

Models and technical tables
Width 2.25 m
Model | Capacity m³ | PTO power HP (kW) | Electric power kW
AS 400 | 8 | 30 (22) | 17
AS 500 | 10 | 35 (26) | 17.5

Width 2.55 m
Model | Capacity m³ | PTO power HP (kW) | Electric power kW
AS 600 | 11.5 | 40 (30) | 21
AS 900 | 15 | 45 (34) | 25
AS 1000 | 17 | 50 (37) | 27
AS 1150 | 19 | 55 (41) | 31

Width 3.2 m
Model | Capacity m³ | PTO power HP (kW) | Electric power kW
AS 1350 | 21 | 65 (49) | 37
AS 1550 | 28.5 | 70 (52) | 39
AS 1750 | 32 | 75 (56) | 42

Width 4 m
Model | Capacity m³ | PTO power HP (kW) | Electric power kW
AS 2550 | 44 | 100 (75) | 54
AS 2650 | 52 | 100 (75) | 55
AS 3150 | 58 | 110 (82) | 57
AS 3550 | 64 | 150 (112) | 85
AS 3750 | 75 | 150 (112) | 85

Characteristics / technical specifications

• Series name: TURBODRY Series.
• Drying method: direct-flame drying with refractory-lined chamber.
• Burner options: diesel standard; methane or LPG on request.
• Drive options: PTO (cardan), electric or mixed.
• Control: electrical panel with automatic and manual modes; temperature sensors for monitoring.
• Product handling: loading auger, central auger, swivel or motorized discharge.
• Cleaning: expulsion cleaner for impurity separation.
• Available capacities: from 8 m³ (AS 400) up to 75 m³ (AS 3750) across multiple widths.
• Power ranges: PTO power and equivalent kW per model; separate electric motor kW per model as listed above.
