Hose Ryltec 2700

dischargerubberpolyester sheath

Product type
Conductive NR rubber mandrel hose with textile reinforcement and steel wire spiral for bulk material suction and discharge.

Description
Mandrel hose with inner tube in conductive natural rubber (NR) with anti-abrasive properties, polyester textile reinforcement and synthetic rubber outer tube. Designed for both suction and discharge (impulsion and suction) of bulk materials.

Performance
Temperature range: -30°C to +80°C.
Working pressure: WP 10 bar (ISO1307).

Marking
RYLTEC 2700 – BULK MATERIAL SUCTION AND DISCHARGE – WP 10 BAR (150PSI) – Ref. Ø.

Available items (table)
Item | Code | Ø (mm)
C314051 | 3654 | 51×67
C314063 | 3655 | 63×78
C314076 | – | 76×91
C314090 | 3657 | 90×110
C314100 | 3658 | 102×119
C314115 | 3660 | 115×135
C314127 | 3663 | 127×146
C314150 | 3661 | 152×171

Technical characteristics

• Inner material: conductive NR (natural rubber) with anti-abrasive properties
• Outer material: synthetic rubber
• Reinforcement: polyester textile reinforcement
• Structure: steel wire spiral
• Intended use: bulk material suction and discharge (impulsion and suction)
• Temperature range: -30°C to +80°C
• Working pressure: 10 bar (ISO1307)
• Marking: RYLTEC 2700 – BULK MATERIAL SUCTION AND DISCHARGE – WP 10 BAR (150PSI) – Ref. Ø
• Available diameters and item codes: see table above
