Mounted disc harrow RX series

with hydraulic adjustmentdepth controlwith roller

Brief description
The RX mounted disc harrow is designed for primary and secondary soil tillage. It features rubber disc protection and mechanical depth adjustment for reliable field operation.

Standard equipment

• Two rows of C-type discs, Ø 560 mm
• Rubber shock absorbers for disc protection
• Tubular, flatbar or serrated flatbar roller Ø 500 mm
• Adjustable side shields
• 95 cm spacing between disc rows
• Reinforced Cat II / Cat III hitch or automatic hitch beam (up to 3 m machine length)

Optional equipment

• Fusion roller Ø 600 mm
• Crosskill roller Ø 500 mm
• V-Ring roller Ø 500 or 600 mm
• Packer roller Ø 500 or 600 mm (with scrapers)
• Tubular roller, serrated Ø 600 mm
• Flex roller Ø 500 mm (with scrapers)
• T-roller Ø 500 mm
• U-roller Ø 500 or 600 mm
• Rubber roller Ø 500 mm
• Ø 610 mm discs (only with maintenance-free hub)
• Hydraulic rear roller adjustment
• Scraper row
• Lights
• Maintenance-free hub
• Working widths 2.0 m, 2.2 m, 2.5 m, 2.7 m (available on special order)

Product number
8521RX, 8522RX, 8523BRX

Technical data
REF.NO.; WORKING WIDTH [M]; DISC DIAMETER [MM]; SPACE BETWEEN THE ROWS [MM]; NUMBER OF DISCS [PCS.]; POWER DEMAND [HP]; WEIGHT [KG]
8521RX; 3.0; 560; 950; 24; 80-110; 1240
8522RX; 3.5; 560; 950; 28; 90-120; 1370
8523BRX; 4.0; 560; 950; 32; 100-130; 1700

Characteristics / technical specifications

• Series: RX series
• Disc diameter: 560 mm standard; 610 mm available with maintenance-free hub
• Spacing between rows: 950 mm
• Standard working widths per model: 3.0 m (8521RX), 3.5 m (8522RX), 4.0 m (8523BRX)
• Number of discs: 24 (8521RX), 28 (8522RX), 32 (8523BRX)
• Power demand: 80–110 HP (8521RX); 90–120 HP (8522RX); 100–130 HP (8523BRX)
• Weight: 1240 kg (8521RX); 1370 kg (8522RX); 1700 kg (8523BRX)
• Depth adjustment: mechanical
• Disc protection: rubber shock absorbers
• Hitch: reinforced Cat II/Cat III or automatic hitch beam (up to 3 m)
