Plastic pallet Nest C5.2 (OD-3R)

polyethyleneISOtransport

Nest C5.2 (OD-3R) is a nestable plastic container pallet designed for heavy loads and optimized for ISO freight transport. It features a three-runner base and an open upper deck to facilitate ventilation and efficient stacking.

Key features

• Three-runner bottom support (3run) for stable handling of heavy loads and smooth operation on roller or chain conveyors.
• Open upper deck to maximize usable deck area and improve load ventilation.
• Manufactured from recycled plastic; reusable and 100% recyclable.
• Optimized for ISO freight containers and block stacking; compatible with conveyor systems.
• Safety rim: 8.5 mm for load retention; 4-way entry.

Available versions

• OD-3R (this product)
• OD-9F, OD-6R, CD-9F, CD-3R, CD-6R (other Nest C5.2 variants)

Technical specifications

• Model: Nest C5.2
• Variant: OD-3R
• Entry: 4-way
• Bottom support: 3run
• Upper deck: open
• Safety rim: 8.5 mm
• Dimensions (mm): 1140 x 1140 x 163
• Static load capacity: 3500 kg
• Dynamic load capacity: 1850 kg
• Racking capacity: 300 kg
• Weight (PE mix): 13.5 kg
• Weight (PP mix): 14.5 kg
• Material: recycled plastic (100% recyclable)
