Plastic pallet Nest C5.2 (CD-3R)

ISOtransportstorage

Nest C5.2 (CD-3R) is a container plastic pallet engineered for heavy loads, featuring a three-runner base and a closed upper deck. Optimized for ISO freight handling and manufactured from a recycled polypropylene blend that is fully recyclable.

Available versions

• Nest C5.2 (CD-3R) — 3-run bottom, closed deck, 1140 x 1140 x 163 mm, static 3500 kg, dynamic 2400 kg, racking 300 kg, weight 16.5 kg
• Nest C5.2 (OD-9F) — 9-foot bottom, open deck, 1140 x 1140 x 140 mm, static 3000 kg, dynamic 1500 kg, weight 11.5 kg
• Nest C5.2 (OD-3R) — 3-run bottom, open deck, 1140 x 1140 x 163 mm, static 3500 kg, dynamic 1850 kg, racking 300 kg, weight 14.5 kg
• Nest C5.2 (OD-6R) — 6-run bottom, open deck, 1140 x 1140 x 163 mm, static 3900 kg, dynamic 2400 kg, racking 300 kg, weight 16.5 kg
• Nest C5.2 (CD-9F) — 9-foot bottom, closed deck, 1140 x 1140 x 140 mm, static 3000 kg, dynamic 1500 kg, weight 13.5 kg
• Nest C5.2 (CD-6R) — 6-run bottom, closed deck, 1140 x 1140 x 163 mm, static 4000 kg, dynamic 2400 kg, racking 300 kg, weight 18.5 kg

Key features

• Three-runner base for stable support and smooth operation on roller or chain conveyors.
• Closed upper deck that protects loads from pressure points and contamination while maximizing usable deck area for stacking.
• Designed for heavy-duty static and dynamic loads and block stacking; includes a safety rim (8.5 mm).
• Constructed from recycled PP mix — reusable and 100% recyclable.

Technical specifications (CD-3R)

• Model: Nest C5.2 (CD-3R)
• Entry: 4 ways
• Bottom support: 3run
• Upper deck: closed
• Dimensions (mm): 1140 x 1140 x 163
• Static load capacity (kg): 3500
• Dynamic load capacity (kg): 2400
• Racking capacity (kg): 300
• Weight (PP MIX) (kg): 16.5
• Safety rim: 8.5 mm
• Nesting height: - mm (not specified)
