Water tank AQ13001H-B

liquid fertilizerstainless steelUV-resistant

Description
Tank with 3-year warranty (tank) and 1-year warranty on parts.
Transport with confidence thanks to a very wide, low-profile design that improves stability and safety on the road.
Handling rings allow straps to pass through for easier empty-tank manipulation.
Versatile: accepts various solutions (liquid fertilizer, molasses, brine, etc.) up to a density of 1.4 Kg/dm3.
Compact footprint for mounting on tipper or flatbed.
Equipped with a 3" stainless steel bulkhead fitting and a DN80 stainless steel valve.
Self-cleaning made simple via the manhole access.
Longer lid life and improved sealing thanks to protective molding and a reinforced base flange.
Reduce tractor wear with the anti-surge / anti-roll design that breaks the wave.
Cover and drain system fully in stainless steel for durability and easy cleaning.

Key advantages

• Reinforced dome structure for improved resistance to pressure and mechanical stress.
• UV15 treatment: twice the resistance of standard UV8 for superior protection against impacts and UV, extending service life.
• Dorsal stop with robust axle fixing: stability, safety and rapid installation (axles optional).
• Note: Speed limited to 25 km/h. For tank volumes ≥ 8,000 L and operation above 25 km/h, installation of Ball Baffles is mandatory. Use of tanks ≥ 8,000 L above 25 km/h without Ball Baffles voids the warranty.

Technical specifications

• Reference: AQ13001H-B
• Model: AQUA 13000
• Capacity (L): 13000
• Height (m): 2.120
• Diameter (m): 2.000
• Bulkhead fitting: 3" stainless steel
• Valve: DN80 stainless steel
• Lid and drain system: stainless steel
• Manhole for cleaning
• Maximum liquid density accepted: 1.4 Kg/dm3
• Compatibility: mountable on tipper or flatbed
• UV treatment: UV15 (higher than standard UV8)
• Anti-roll design to reduce vehicle wear
• Warranty: tank 3 years; parts 1 year
